Turbosmart TS-0565-1762 Pneumatic StraightGate50 External Wastegate 6 PSI

Product Description
$751.49
Maximum quantity available reached.

Turbosmart designed their TS-0565-1762 StraightGate50 as the world's highest-flowing 50mm external wastegate! This zero-offset butterfly-style wastegate allows enormous flow and almost linear control, as well as unparalleled boost control throughout the entire operating range. The Boost-Based Pneumatic StraightGate50 wastegate simplifies control via a traditional boost-based actuator. In addition, the Self-Balancing nature of the StraightGate50 means a huge tuning window of over 5 times base spring pressure can be obtained!

Pre-fitted with 6 psi springs to the GenV actuator featuring both Single and Twin port control, the StraightGate50 is simple to use, and packed with performance, flow and features! The increased flow is achieved through the efficiency of a straight-through valve versus a poppet-style valve where the exhaust gas must be turned 90 degrees by the valve.

Turbosmart TS-0565-1762 StraightGate50 Wastegate Features:

  • 50mm (1.97in) Butterfly Style Zero-Offset Valve
  • 383.9 CFM / 10.87m3 per minute flow
  • Stainless Steel (630) Butterfly and shaft
  • Stainless Steel (347) Main Body
  • Stainless Steel (Heat Treated 431) V-Band Clamps
  • Aluminium (6262 T6 Anodized) Bracket and Actuator
  • Turbosmart unique Locking Collar Ring
  • Base Spring Options from 6psi to 42psi
  • Suitable for either Single or Twin Port Boost-Based Control
  • Stainless Steel (N60) Linkages and Control Arm

Additional Features:

  • Wastegate Style: Diaphragm
  • Wastegate Location: External
  • Wastegate Type: Mechanical
  • Wastegate Base Material: Stainless Steel
  • Top Cap Color: Black Anodized
  • Top Cap Material: Aluminum
  • Mounting Flange Included: Yes
  • Flange Style: Weld-On
  • Mounting Flange Material: Stainless Steel
  • Reference Ports Included: Yes
  • Fittings Included Also: Yes
  • Quantity: Sold individually

Turbosmart has boost controllers, blowoff valves, wastegates, as well as fuel management systems found on vehicles all over the world. In addition, they offer replacement/upgrade components for a number of popular vehicle models.

Sku: TBSTS-0565-1762
Vendor: TURBOSMART
